| Product Name | Galvanized Steel Pipe / Tube |
| Material | Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD,S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,SGH540,SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230),SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80(550), CQ,FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement |
| Size | Customized |
| Zinc coated | 30g-275g/m2 |
| Type of Coating | Hot Dipped Galvanized Steel |
| Surface Treatment | Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P),Untreated(U) |
| Surface Structure | Normal spangle coating(NS), minimized spangle coating(MS),spangle-free(FS) |
| Coil ID | 508mm or 610mm |
| Standard | JIS 3302 / ASTM A653 /EN10143 AISI , ASTM , DIN , GB , JIS G3302 G3312 G3321 , BS |
| Technique | Hot Rolled / Cold Rolled |
| Product Application | 1. Fence, greenhouse, door pipe,greenhouse 2. Low pressure liquid, water, gas, oil, line pipe 3. For both indoor and outdoor the building construction 4. Widely used in scaffolding construction which is much cheaper and convenient |
| Origin | China |
| Certificates | API ISO9001-2008,SGS.BV |
| Delivery Time | Usually within 10-45 days after receipt of advance payment |
